Core Advantages
Ultra-large single batch loading capacity: ZB-200 holds 180kg per batch while ZB-330 reaches 280kg. Equipped with 6 heavy-duty alloy chopping blades, featuring multi-stage segmented blade speeds (750/1500/3000/4200 RPM) and full variable frequency stepless speed regulation.
Multi-range adjustable bowl speed from 0–15 r/min, suitable for massive batches of frozen raw meat. It delivers uniform emulsification and ultra-high water retention rate, ideal for round-the-clock continuous mass production at 10,000-ton meat processing factories.
Heavy industrial thickened frame with full set of high-power drive motors, matched with high-flow automatic discharging device. The power of discharge motor is upgraded to 2.2KW / 4KW to provide uninterrupted feeding for production lines.
The whole machine is constructed with thickened SUS304 stainless steel, fitted with waterproof and explosion-proof electric control system, complying with high-standard hygiene and safety codes of European and American food plants, perfectly matching large export production lines.
Technical Parameters
| Model | Single Batch Capacity | Overall Dimension (mm) | Blade Qty | Blade Speed (r/min) | Bowl Speed (r/min) | Discharge Speed | Voltage | Total Power | Main Motor | Bowl Motor | Discharger Power |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Variable Frequency ZB-200 | 180kg | 2800×2200×1700 | 6 | 0–3000 | 0–15 | 83r/min | 380V 50Hz | 64KW | 52KW | 4.5KW | 2.2KW |
| Variable Frequency ZB-330 | 280kg | 3810×2965×1800 | 6 | 750/1500/3000/4200 | 4/8/11/15 | 83r/min | 380V 50Hz | 96.2KW | 75KW | 5.5KW | 4KW |
Application Scenarios
Large-scale 10,000-ton deep-processing meat factories, large industrial parks for mass-produced wet pet food, fully automatic production lines for frozen prepared food, large-scale surimi & fish ball manufacturing bases.
Certifications & Supporting Services
Our self-owned factory holds EU CE machinery certification, US FDA facility registration and multiple utility model patents for food processing machinery. Operating as an integrated manufacturer & foreign trade enterprise, we provide one-stop services including customized blade profiles, complete export customs clearance documents, on-site installation & commissioning, and lifelong supply of original factory chopping blade spare parts.
Consult our engineers via the website form for quotations, real machine operation videos and full production line matching & selection solutions.
