125L Vacuum Bowl Cutter
Core Advantages
1. 90kg Large Batch & Two Speed Modes
This 125L Vacuum Bowl Cutter adopts a 90kg single-batch design and is equipped with 6 high-strength chopping blades. Two power configurations including dual fixed speed and variable frequency are optional, perfectly matching fully automatic continuous meat production lines for mass processing.
2. High Torque Motor, Direct Frozen Meat Processing
The 125L Vacuum Bowl Cutter is equipped with a high-power main motor to output strong torque. Frozen meat raw materials can be directly put into the machine for emulsification. Products processed by this 125L Vacuum Bowl Cutter own much better elasticity and tenderness than small-size bowl cutters.
3. Dual Adjustable Bowl Speed, No Material Agglomeration
The 125L Vacuum Bowl Cutter supports switchable bowl speeds of 12 / 16 r/min, which makes raw materials circulate fully inside the bowl without lumps or coarse particles. It is highly suitable for premium luncheon meat, crispy sausages and pet meat snacks.
4. Heavy Frame & Automatic Discharge System
The whole machine of the 125L Vacuum Bowl Cutter uses thickened heavy stainless steel frame to support 24-hour uninterrupted production. The built-in automatic discharging device can be directly connected to downstream filling and forming machines for streamlined production.
Technical Parameters
| Model | Single Batch Capacity | Overall Dimension (mm) | Blade Qty | Blade Speed (r/min) | Bowl Speed (r/min) | Discharge Speed | Voltage | Total Power | Main Motor | Bowl Motor | Discharger Power |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Dual-speed ZB-125 | 90kg | 2020×1450×1300 | 6 | 1800 / 3000 | 12 / 16 | 83r/min | 380V 50Hz | 21.85KW | 15 / 18.5KW | 2.2 / 2.8KW | 0.55KW |
| Variable Frequency ZB-125 | 90kg | 2020×1450×1300 | 6 | 0–3000 | 12 / 16 | 83r/min | 380V 50Hz | 26KW | 22KW | 2.2 / 2.8KW | 0.55KW |
Application Scenarios
The 125L Vacuum Bowl Cutter is widely used in large ham sausage deep processing bases, full-automatic wet pet food production lines, high-end fish tofu & crystal sausage factories and central kitchen ready meal industrial parks.
Certifications & Supporting Services
We independently produce the 125L Vacuum Bowl Cutter, with EU CE certification and US FDA factory registration, and a number of food machinery utility patents. As an integrated manufacturer and foreign trade supplier, we offer one-stop solutions: customizable blade types, full export documents, on-site installation and commissioning, and lifelong supply of original chopping blades. You can contact our engineers through the website form to get quotations, operation videos and complete production line matching plans.
