750‑1500L ZKBX Large Industrial Vacuum Meat Mixer Product Overview
The ZKBX Series Large Industrial Vacuum Meat Mixer covers capacities from 30L up to 1500L with full SUS304 food‑grade stainless steel construction. Vacuum negative‑pressure stirring removes internal air bubbles, improving meat elasticity, water‑holding capacity and final product quality. Equipped with PLC programmable control storing up to 99 production formulas, its high‑low double auger mixing structure solves powder agglomeration and uneven blending issues. The single discharge outlet leaves no sanitary dead corners and supports direct water flushing for simple sanitation.
While 30‑500L units serve delis and small prepared‑food workshops, the 750‑1500L large industrial vacuum meat mixer models are built for heavy‑duty fully‑automatic large‑scale meat and wet‑pet‑food production lines. All ZKBX series machines come with complete CE and FDA export certifications.
The Large Industrial Vacuum Meat Mixer Core Advantages
Heavy‑Duty Thickened Stainless Steel Frame, 24‑Hour Continuous Mass Production
Reinforced mixing chamber made of thick SUS304 stainless steel supports non‑stop batch processing of meat batter, surimi and pet meat paste around the clock. It can connect with meat flakers, bowl cutters and sausage stuffers to build complete automated production lines.
High‑Power Drive & 63L Large‑Flow Vacuum Pump, Stable ‑0.09Mpa Vacuum Degree
Main drive motor power ranges from 7.5KW to 22KW, paired with a large‑capacity 63L vacuum pump. It maintains stable ‑0.09 Mpa vacuum even during long‑run continuous manufacturing, delivering bubble‑free, non‑stratified fillings for huge batch outputs.
PLC Intelligent Control with 99 Storable Formulas for Standardized Factory Production
Up to 99 editable process programs support segmented stirring, intermittent standing, and forward‑reverse mixing timing. Perfect for standardized processing of ham, luncheon meat and high‑grade wet pet food in large‑volume plants.
3‑Layer Composite High‑Low Auger Mixing, Homogeneous Blending for High‑Ton Output
Three‑in‑one mixing assembly combining paddle, blade and ribbon. Large‑batch materials achieve full vertical circulation inside the tank. High‑viscosity meat paste and coarse‑fiber fruit‑vegetable additives blend uniformly without agglomeration for consistent end‑product texture.
Direct‑Coupled Reducer Transmission, Low Noise & Extended Service Life Under Heavy Load
Heavy‑duty direct‑coupled design cuts transmission loss and generates high torque. It resists overload under dense thick fillings, lengthens maintenance intervals and reduces factory downtime losses.
Large‑Caliber Single‑Side Discharge Outlet, Seamless Integration With Automatic Lines
Enlarged single‑side discharge outlet realizes smooth material evacuation with minimal residual material. Outlet height matches conveyors and transfer pumps to enable unmanned continuous feeding for industrial workflows.
Technical Parameters (750‑1500L Large‑Capacity Models)
Model | Single Batch Capacity (kg) | Overall Dimension (mm) | Voltage 50Hz | Drive Motor Power | Vacuum Pump Volume | Vacuum Pump Power | Vacuum Degree | Mixing Structure |
|---|---|---|---|---|---|---|---|---|
ZKBX‑750 | 500 | 2100×1800×1900 | 380V | 7.5KW | 63L | 1.5KW | -0.09Mpa | Paddle + Blade + Ribbon |
ZKBX‑1200 | 900 | 2060×1700×2450 | 380V | 15KW | 63L | 4.5KW | -0.09Mpa | Paddle + Blade + Ribbon |
ZKBX‑1500 | 1200 | 2260×1700×2450 | 380V | 22KW | 63L | 4.5KW | -0.09Mpa | Paddle + Blade + Ribbon |
Application Scenarios
Medium‑large ham and luncheon meat processing factories, fully‑automatic wet pet food industrial parks, large‑scale frozen surimi production lines, 10 000‑ton standardized prepared‑meal manufacturing bases.
Certifications & Supporting Services
Our self‑owned factory holds EU CE mechanical certification, US FDA facility registration and multiple food‑machinery utility‑model patents. The ZKBX series supports custom tank volume. We supply complete export customs documents, on‑site installation & commissioning, plus lifelong original spare‑parts supply for mixing augers, vacuum pumps and transmission assemblies.
Contact our engineers via the website form for quotations, real‑operation videos and full‑production‑line matching schemes.
